HIGHLIGHTS:
- Immediate visualisation of temperature differences with smart documentation
- Fast exchange of data and easy documentation of thermal images with the Bosch Measuring Master app
- Picture-in-picture technology overlays thermal and real images for easy-to-see localisation of the measurement
- Flexible battery system can be powered by a 12 V LI-ION battery or with standard alkaline batteries.
SPECIFICATIONS:
- Measurement range : -10 °C to +400 °C
- Measuring accuracy of IR : ±3.0 °C
- Optics (Ratio of meas. distance : meas. spot) : 0
- Resolution : 0.1 °C
- Thermal sensitivity (NETD) : <50 mK
- Size of IR sensor : 160x120 px
- Number of measuring points : 19,200
- Power supply and runtime : 4 x 1.5 V LR6 (AA) 1 x GBA 12V 1 x GBA 10.8V
- Frame buffer (number of images) : 500
- Memory type : Internal memory
- Internal memory : .jpg
- Data transfer : MicroUSB , Wi-Fi
- Dust and splash protection : IP 53
- Weight : 0.54 kg
- Supported Android devices : Smartphone with Android 4.3 or higher , Tablet with Android 4.3 or higher
- Supported iOS devices : iPad (3rd Gen. or higher) , iPad Air (1st Gen. or higher) , iPad mini (1st Gen. or higher) , iPhone 4S or higher
- Display type : TFT LCD
- Size of display : 3,5"
- Operating temperature : -10 – 45 °C
- Storage temperature : -20 – 70 °C
- Working range : 0
