Calpeda Submersible Open Impeller Drainage Pump, Stainless Steel, 1-Phase (MADE IN ITALY)
CONSTRUCTIONSingle-impeller submersible pumps in chrome-nickel stainless steel, with vertical delivery port. GXR: with open impeller. GXV: with free-flow (vortex) impeller. Motor cooled by the pumped water passing between the motor jacket...
Select billease during checkout.
CONSTRUCTION
Single-impeller submersible pumps in chrome-nickel stainless steel, with vertical delivery port.
GXR: with open impeller.
GXV: with free-flow (vortex) impeller.
Motor cooled by the pumped water passing between the motor jacket and the external jacket.
Double shaft seal with oil chamber.
Minimum dimension and high levels of performance, for use in many different applications, head up to 12,7 m and flow rates up to 220 liters/min.
APPLICATIONS
GXR: - For clean water containing solids up to 10 mm grain size. - For draining rooms or or emptying tanks. - Extraction of water from ponds, streams or pits and for rainwater collection. - For irrigation purposes.
GXV: - For clean or slightly dirty water, containing solids up to 25 mm grain size.
- Particularly suitable for liquids with a high solid content.
For outdoor use a power supply cable of not less than 10 m should be used in accordance with: EN 60335-2-41.
OPERATING CONDITIONS
Liquid temperature +5 °C to +50° C.
Maximum immersion depth: 5 m.
Minimum water level with float: GXR = 70 mm, GXV = 130 mm.
Minimum water level manual operation: GXR = 15 mm, GXV = 30 mm. Continuous duty.
MOTOR
2-pole induction motor, 60 Hz (n ≈ 3450 rpm).
GXRM, GXVM: single-phase 220 V, with float switch, with thermal protector only 220V. Incorporated capacitor only 220V.
Cable: H07RN-F (H05RN-F for 0,25 kW), length 5 m, with plug CEI-UNEL 47166.
Insulation class F.
Protection IP X8 (for continuous immersion)
Double impregnation humidity-proof dry winding.
Constructed in accordance with: EN 60335-2-41.
| Component | Material |
|---|---|
| Pump casing | Cr-Ni steel 1.4301 EN 10088 (AISI 304) |
| Strainer | Cr-Ni steel 1.4301 EN 10088 (AISI 304) |
| Impeller | Cr-Ni steel 1.4301 EN 10088 (AISI 304) |
| Motor jacket | Cr-Ni steel 1.4301 EN 10088 (AISI 304) |
| Pump jacket | Cr-Ni steel 1.4301 EN 10088 (AISI 304) |
| Handle | Polypropylene |
| Shaft | Cr-Ni steel 1.4305 EN 10088 (AISI 303) |
| Mechanical seal | Ceramic alumina/Carbon/NBR |
| Seal lubrication oil | Oil for food/pharmaceutical machinery |
|
PUMP MODEL |
MOTOR |
IMPELLER MATERIAL |
|
|
KW |
HP |
||
| GXRm (9-60) | 0.25 | 0.33 | AISL |
| GXRm (11-60) | 0.37 | 0.5 | AISL |
| GXRm (13-60) | 0.45 | 0.6 | AISL |
| GXRm (12-10-60) | 0.45 | 0.6 | AISL |
| GXRm (12-12-60) | 0.55 | 0.75 | AISL |
| GXRm (12-14-60) | 0.75 | 1 | AISL |
| GXRm (12-16-60) | 0.9 | 1.2 | AISL |
| GXRm (12-18-60) | 1.1 | 1.5 | AISL |
| GXRm (12-20-60) | 1.5 | 2 | AISL |
| GXVm (25-6-60) | 0.25 | 0.33 | AISL |
| GXVm (25-7-60) | 0.25 | 0.33 | AISL |
| GXVm (25-8-60) | 0.37 | 0.5 | AISL |
| GXVm (25-10-60) | 0.45 | 0.6 | AISL |
| GXVm (40-7-60) | 0.55 | 0.75 | AISL |
| GXVm (40-8-60) | 0.75 | 1 | AISL |
| GXVm (40-9-60) | 0.9 | 2 | AISL |
