Description
FEATURES:
- HSS drill bits; to DIN338 featuring M35 steel with 5% cobalt content. This means the bit is stronger and lasts longer compared to traditional HSS drill bits.
- Ideal for use with stainless steel; hard alloys; abrasive materials; cast iron and ferrous metals
- 5% cobalt content offers maximum heat and abrasion resistance for use with hard materials
- 135 DEG split point tip geometry prevents bit walking for fast and accurate material penetration
- Ground forged edge and flute construction for high quality performance and long life
- Made In Japan
Bit ø (Inches) | Overall Length | Working Length |
Piece per Pack |
Part No. |
1/16" |
1-7/8" |
7/8" |
2 |
D-22523 |
5/64" |
2" |
1" |
2 |
D-22539 |
3/32" |
2-1/4" |
1-1/4" |
2 |
D-22545 |
7/64" |
2-5/8" |
1-1/2" |
2 |
D-22551 |
1/8" |
2-3/4" |
1-5/8" |
2 |
D-22567 |
9/64" |
2-7/8" |
1-3/4" |
2 |
D-22573 |
5/32" |
3-1/8" |
2" |
1 |
D-22589 |
11/64" |
3-1/4" |
2-1/8" |
1 |
D-22595 |
3/16" |
3-1/2" |
2-5/16" |
1 |
D-22604 |
13/64" |
3-5/8" |
2-7/16" |
1 |
D-22610 |
7/32" |
3-3/4" |
2-1/2" |
1 |
D-22626 |
15/64" |
3-7/8" |
2-5/8" |
1 |
D-22632 |
1/4" |
4" |
2-3/4" |
1 |
D-22648 |
17/64" |
4-18" |
2-7/8" |
1 |
D-22654 |
9/32" |
4-1/4" |
2-15/16" |
1 |
D-22660 |
19/64" |
4-3/8" |
3-1/16" |
1 |
D-22676 |
5/16" |
4-1/2" |
3-3/16" |
1 |
D-22682 |
21/64" |
4-5/8" |
3-5/16" |
1 |
D-22698 |
11/32" |
4-3/4" |
3-7/16" |
1 |
D-22707 |
23/64" |
4-7/8" |
3-1/2" |
1 |
D-22713 |
3/8" |
5" |
3-5/8" |
1 |
D-22729 |
25/64" |
5-1/8" |
3-3/4" |
1 |
D-22735 |
13/32" |
5-1/4" |
3-7/8" |
1 |
D-22741 |
27/64" |
5-3/8" |
3-15/16" |
1 |
D-22757 |
7/16" |
5-1/2" |
4-1/16" |
1 |
D-22763 |
29/64" |
5-5/8" |
4-3/16" |
1 |
D-22779 |
15/32" |
5-3/4" |
4-5/16" |
1 |
D-22785 |
31/64" |
5-7/8" |
4-3/8" |
1 |
D-22791 |
1/2" |
6" |
4-1/2" |
1 |
D-22800 |
Bit ø (mm) |
Overall Length |
Working Length |
Piece |
Part No. |
3.0 |
61 |
33 |
1 |
D-17310 |
4.0 |
75 |
43 |
1 |
D-17348 |
5.6 |
86 |
52 |
1 |
D-17360 |
6.0 |
93 |
57 |
1 |
D-17382 |
8.0 |
117 |
75 |
1 |
D-17429 |
10.0 |
133 |
87 |
1 |
D-17463 |
13.0 |
151 |
101 |
1 |
D-17522 |
