Description
HIGHLIGHTS:
- Continuous rating input : 1,750 W
- Blade diameter : 305 mm (12")
- Maximum cutting capacity at 0° : 115 mm (4-1/2")
- Maximum cutting capacity at 0° : 75 x 150 mm (2-15/16" x 5-7/8")
- Maximum cutting capacity at 45° : 90 mm (3-1/2")
- Maximum cutting capacity at 45° : 85 x 85 mm (3-5/16" x 3-5/16")
- No load speed : 1,300 rpm
- Dimensions : 51.6 cm x 30.6 cm x 60.3 cm (20-1/4" x 12" x 23-3/4")
- Net weight : 19.3 kg (42.5 lbs)
- Power supply cord : 2.5 meters (8.2 feet)
DESCRIPTION:
- Fast cuts in light pipe, angle iron, tubing, conduit and channels.
- Tool-less cutting angle adjustment.
- Carbide tipped blade lasts longer than abrasive wheel; cuts clean, accurate and virtually burr-free.
- Double insulation.
- Specially designed TCT blade provides accurate cold cuts in mild steel pipe, angle iron, tubing, conduit and channels.
- Exceptionally clean - virtually burr free cuts
- Quick release vice
- Quick release lever to adjust cutting angle - no tools required
- lock off button prevents accidental starts
- shaft lock for easy blade change
- swarf collection tray for cleaner work environment
Continuous rating input | 1,750W |
Blade Diameter | 305 mm (12″) |
Max Cutting Capacity | 90°: 115 mm (4-1/2″) |
90°: 75 x 150 mm (2-15/16″ x 5-7/8″) | |
45°: 90 mm (3-1/2″) | |
45°: 85 x 85 mm (3-5/16″ x 3-5/16″) | |
No Load Speed (RPM) | 1,300 |
Dimensions (L x W x H) | 516x306x603 mm (20-1/4″x12″x23-3/4″) |
Net weight | 19.3 kg (42.5 lbs) |
Power supply cord | 2.5 m (8.2 ft) |
WHAT'S IN THE BOX:
- 1 x Makita LC1230 12" Metal Cutting Saw 1,750W
- 1 x Makita Carbide tipped saw blade
- 1 x Makita Socket Wrench
- Safety Goggles
