- High power delivered by 40Vmax BL motor enables to cut as fast as if you were using a corded slide compound miter saw
- Vacuum cleaner activation switch for increased comfort
- LED light with ink line aligning function
- Auto-start Wireless System (AWS) connects to compatible vacuum cleaners with Bluetooth
- Rail-forward design enables to be placed against a wall for maximizing work space
- Large turn base supports workpiece securely for increased stability
- Integrated guide fences for increased rigidity and high cutting accuracy
- Increased dust extraction rate for a cleaner work environment
- Single sliding system enables smooth operation to produce superior cuts
- Front knob for easy bevel angle adjustment
- Increased sliding durability of safety cover
- Slide lock for locking the sliding movement of the carriage
- Holders are provided on both sides of the tool to hold long workpieces horizontally
- Largest crown molding cutting capacity in its class
- Exclusive linear ball bearings engineered to deliver “dead-on” accurate cuts
- Increased capacity for up to 203 mm (8″) crown molding (vertically nested), 171 mm (6-3/4″) baseboard (vertical), and 382 mm crosscuts at 90°
- Innovative direct drive gearbox and guard system is engineered for increased vertical cutting capacity
- Miters 0°-60° left and right, with positive stops at 0°, 15°, 22.5°, 31.6°, 45° and 60° (left and right)
- Compact and lightweight for easy jobsite portability.
- Powerful direct drive motor requires less maintenance and delivers 3,600 RPM.
- Exclusive 140 mm (5-1/2″) tall dual sliding fence system features upper and lower fence adjustments for more precise miter and bevel cuts.
- Ergonomic rubberized horizontal D-handle design for better fit and added comfort.
- Soft start feature for smooth start-ups.
- See-through blade guard system for greater visibility of blade and line of cut.
- Easy one-step blade changes for increased efficiency.
- Rubberized feet help tool remain stationary.
- Oversized trigger switch for better fit, added comfort and easier operation.
- Lock-off (2 stage) safety switch for increased operator safety.
- Electric brake for maximum productivity.
- Incorporates Deep eXact cutting Technology (DXT) achieved by our consistent pursuit of cutting larger size workpiece but with higher accuracy.
- On-tool hex wrench for fast and easy blade changes and keeping it from lost.
- Battery protection circuit protects against overloading, over-discharging and over-heating
TCT Saw Blade, Dust Bag, Triangular Rule, Vertical Vise, Hex Wrench, Wireless Unit (WUT09)
|Wheel Diameter||305 mm (12″)|
|Blade Diameter||305 mm (12″)|
|Hole Diameter||25.4 mm (1″)|
|Miter Angle||60° L 60° R|
|Bevel Angle||48° L 48° R|
|Max Cutting Capacity||0° Miter: 107 x 363 mm (4-1/4 x 14-1/4″)|
|45° Miter, L/R: 107 x 255 mm (4-1/4 x 10″)|
|No Load Speed (RPM)||3600|
|Max Output||1,500 W|
|Sound Pressure Level||91 dB(A)|
|Sound Power Level||100 dB(A)|
|Noise K Factor||3 dB(A)|
|Dimensions (L x W x H)||898 x 690 x 725 mm (35-1/4 x 27-1/4 x 28-1/2″)|
|Net weight||30.5 – 31.1 kg (67.2 – 68.6 lbs.)|
