Mitutoyo Digital Absolute Caliper Coolant-Proof IP67, Series 500

Name: Mitutoyo Digital Absolute Caliper Coolant-Proof IP67, Series 500
Brand: Mitutoyo
SKU: 45476083532008
Price: 13944.0 PHP
Availability: InStock

₱13,944.00

HIGHLIGHTS: The Mitutoyo ABSOLUTE coolant proof caliper delivers accurate, repeatable outside dimension, inside dimension, depth and step measurements with accuracy and unrestricted speed in an ergonomic design. The caliper’s slide and...

Ask a Question

TYPE: METRIC

METRIC

INCHES/METRIC

RANGE: 0-150mm (500-712-20)

0-150mm (500-712-20)

0-150mm (500-702-10)

0-200mm (500-703-20)

0-200mm (500-713-20)

0-200mm (500-717-20)

0-200mm (500-703-10/20)

0-300mm (500-714-10)

6"/150mm (500-762-20)

6"/150mm (500-752-20)

8"/200mm (500-753-20)

12"/300mm (500-754-20)

Add to Wishlist

People are viewing this right now

Responsive Image

Select billease during checkout.

Description

HIGHLIGHTS:

The Mitutoyo ABSOLUTE coolant proof caliper delivers accurate, repeatable outside dimension, inside dimension, depth and step measurements with accuracy and unrestricted speed in an ergonomic design. The caliper’s slide and jaws are constructed of hardened stainless steel and provide an impact-resistant, easy-to-ready LCD display for durable, reliable use. The ABSOLUTE caliper can be used in workshop conditions exposed to coolant, water, dust and oil.

Available in Metric and Inch/Metric models
Available with or without SPC output capabilities
Character height on the LCD display increased from 7.4mm to 9.0mm for improved readability
Redesigned battery cover eliminates the need for a screwdriver
ABSOLUTE (ABS) linear scale eliminates the need for setting the origin point every time the micrometer is powered on
Origin reset is not required even when data is re-displayed after loss due to insufficient illumination during use
Stainless steel construction protects caliper components and ensures accurate performance for longer duration
SPC output function allows for quick and easy data management in real time
Functions include Auto On/Off, Origin Set, Zero-Setting, Data Output and inch/mm conversion (on inch/metric models only)
Alarm: Counting value composition error
IP67 protection eliminates dust ingress, protects against temporary water submersion; permits use in environments exposed to cutting oil, dust, etc.
Unnecessary to wipe or clean the scale
Supplied in a fitted plastic case

**SPECIFICATIONS:**
Order No.:	Units:	SPC Output:	Range:	Resolution:	Accuracy:	Repeatability:	Mass:	Remarks:
500-712-20	Metric	Yes	0-150mm	0.01mm	±0.02mm	0.01mm	168g	-
500-702-10	Metric	No	0-150mm	0.01mm	±0.02mm	0.01mm	168g	-
500-703-20	Metric	No	0-200mm	0.01mm	±0.02mm	0.01mm	198g	-
500-713-20	Metric	Yes	0-200mm	0.01mm	±0.02mm	0.01mm	198g	blade, thumb roller
500-717-20	Metric	Yes	0-200mm	0.01mm	±0.02mm	0.01mm	198g	blade
500-703-10/20	Metric	No	0-200mm	0.01mm	±0.02mm	0.01mm	198g	-
500-714-10	Metric	Yes	0-300mm	0.01mm	±0.03mm	0.01mm	350g	-
500-762-20	Metric, Inch	Yes	0-150mm / 0-6"	0.01mm / 0.0005"	±0.02mm / ±0.0010"	0.01mm / 0.0005"	168g	-
500-752-20	Metric, Inch	No	0-150mm / 0-6"	0.01mm / 0.0005"	±0.02mm / ±0.0010"	0.01mm / 0.0005"	168g	-
500-754-20	Metric, Inch	No	0-300mm / 0-12"	0.01mm / 0.0005"	±0.03mm / ±0.0015"	0.01mm / 0.0005"	350g	-

Warranty

Mitutoyo Warranty Coverage

6 months warranty against factory defects under normal operating conditions.
Applicable to the wide range of Mitutoyo precision measuring tools, including calipers, micrometers, dial indicators, and related instruments.
Subject to inspection and evaluation by an Authorized Service Center to determine warranty eligibility.
Warranty is void if tool inaccuracy or failure is due to improper storage, exposure to extreme temperatures, corrosive environments, or lack of proper cleaning and maintenance.
Rejected: Claims will be denied if damage results from dropping, physical impact, unauthorized disassembly, improper calibration attempts, or any user negligence (User Error).

Please retain your original proof of purchase. Warranty claims are valid only with proper documentation submitted within the warranty period.

Mitutoyo: Precision is our Profession. Only with GIGATOOLS.

Downloads

Brochure | Mitutoyo Absolute Coolant-Proof Caliper
