Mitutoyo Spherical Face Micrometer-Spherical Anvil & Spindle - Series 295

₱8,316.00

HIGHLIGHTS: The Mitutoyo spherical micrometer is available with either a spherical face on the anvil and a flat spindle measuring surface or with spherical measuring surfaces on the anvil and spindle,...

Ask a Question

TYPE: METRIC

METRIC

RANGE: 0-25mm

0-25mm
Add to Wishlist
10 People are viewing this right now

Guaranteed Safe Checkout

INSTALLMENT payment is available via BILLEASE (Click for Details).

Pickup available at Gigatools Warehouse

Usually ready in 2-4 days

Manufacturer Partner & Authorized Reseller. Click below to view more:

Mitutoyo
Description

HIGHLIGHTS:

The Mitutoyo spherical micrometer is available with either a spherical face on the anvil and a flat spindle measuring surface or with spherical measuring surfaces on the anvil and spindle, depending on the application. A ratchet-stop mechanism provides uniform pressure on a workpiece for precise, repeatable measurements and eliminates over-speed error. The micrometer has a measurement range of 0 to 1.0″ (0 to 25.4mm), resolution of 0.00005″ (0.001mm), and an accuracy of +/- 0.0001″



FEATURES:

  • Available with spherical anvil and flat spindle or with spherical anvil and spherical spindle
  • Designed to measure the wall thickness of various tubing, curved parts and pipe wall thickness
  • Spherical measuring faces are 0.59” in diameter and carbide-tipped for durability
  • Ratchet mechanism provides an audible click to ensure measurement is performed at a constant force
  • Knurled friction thimbles provide quick adjustments even when wearing gloves
  • Satin chrome finish on the sleeve and laser etched scale on thimble for easier reading
  • Frame has a baked enamel finish for durability and longer lifespan
  • Includes a standard bar except for 0-25mm and 0-1” models
  • Supplied in fitted plastic case



SPECIFICATIONS:
Order No.: Units: Range: Accuracy: Graduation: Anvil/Spindle: Flatness: Remarks:
295-115 Metric 0-25mm ±3µm 0.01mm S-F 0.6µm D: 10mm
