Sanwa CD5001 Digital Multimeter with True RMS and EF Sensing

₱5,643.00

HIGHLIGHTS: The all-new SANWA CD5001 is a professional grade, true RMS digital multimeter designed for precise and reliable measurements in low-voltage electrical work.  With a robust CAT. IV 600V and CAT....

Ask a Question
Add to Wishlist
People are viewing this right now

Responsive Image
Responsive Placeholder Image

Select billease during checkout.

Manufacturer_Partner
Sanwa
Description

HIGHLIGHTS:

The all-new SANWA CD5001 is a professional grade, true RMS digital multimeter designed for precise and reliable measurements in low-voltage electrical work.

With a robust CAT. IV 600V and CAT. III 1000V rating, it ensures safety and accuracy in demanding environments. It features true RMS and EF (Electric Field) sensing for accurate readings, a full 4-digit 9999 count display, and an auto voltage function that distinguishes between DC and AC voltage. With its compact design, large display and advanced functionality, this multimeter is a solid and reliable tool for professionals and hobbyists alike.

  • True RMS Accuracy: Delivers precise readings for both sinusoidal and non-sinusoidal signals.
  • Full 4-Digit 9999 Count Display: Provides high-resolution measurements.
  • EF (Electric Field) Sensing: Detects electromagnetic fields for enhanced troubleshooting.
  • AUTO V Function: Automatically identifies AC or DC voltage for seamless operation.
  • Auto Hold Function: Stabilized measurements are held automatically for easy recording.
  • User-Friendly Design: Large, backlit display for readability and a lightweight, ergonomic build for comfort.
  • Auto Power Off: Conserves battery life by shutting down after 30 minutes of inactivity, with an option to disable.



SPECIFICATIONS:
CD5001
Function Measuring Range Accuracy Resolution Input Impedance
DCV 999.9m / 9.999 / 99.99 / 999.9V ±(0.5%+2) 0.1mV 10MΩ ~ 11MΩ
ACV 999.9m / 9.999 / 99.99 / 999.9V ±(1.0%+5) 0.001V 10MΩ ~ 11MΩ
Resistance 999.9 / 9.999k / 99.99k / 999.9k / 9.999M / 99.99MΩ ±(0.5%+5) 0.1Ω
Capacitance 999.9n / 9.999μ / 99.99μ / 999.9μ / 9.999m / 99.99mF ±(5%+5) 0.1nF
Frequency 9.999 / 99.99 / 999.9 / 9.999k / 99.99kHz ±(0.1%+5) 0.001Hz
Continuity Buzzer sounds at 30 to 70Ω or less. Open voltage: approx. 0.6V
EF Detection Detects ACV and EF of approx. 80V or more


Display Numeral display 9999
Sampling rate 5 times/sec.
Bandwidth 40 ~ 400Hz (Sine wave)
Battery LR03 x 2
Battery life Approx. 550h at DCV range
Size/Mass H149 × W72 × D37mm / Approx. 232g
Safety standards IEC61010 CAT.IV600V / CAT.III1000V
Downloads
PDF User Guide | CD5001
PDF Data Sheet | CD5001
